Honeywell XNX-AMAE-NNIV1 XNX universal gas transmitter. Our company is specialized in providing Honeywell gas analysis products with guaranteed quality.
The Honeywell XNX is a universal transmitter for toxic, oxygen and combustible gas detection which supports the widest range of sensors on a common platform and offers a modular choice of inputs and outputs. XNX is designed for flexible integration, simple installation, user-friendly operation and straight-forward maintenance. It is ideal for use with a range of gas monitoring controllers or industry standard PLCs. The introduction of our HART Enhanced Device Descriptor Language (EDDL) & Device Type Manager (DTM) software provides users with an at-a-glance indication of the health of their gas detectors in the field.
There are three versions of the Honeywell XNX Universal Gas Transmitter available supporting millivolt, electrochemical cell and infrared gas detection. The IR and electrochemical cell versions require the purchase of a compatible sensor separately. The XNX's advantage comes from a simple-to-use, low-maintenance universal platform that works with other safety equipment on a digital bus system, including Honeywell Analytics' own Searchline Excel, Optima or other gas detectors, industry standard PLCs and third-party gas monitoring controllers.
The XNX offers a variety of communication options to suit your industrial operation's unique and changing needs. HART communication comes standard on the XNX — with optional EDDL — along with optional Modbus, Foundation Fieldbus or relays. It can interface with a PLC and a host of other protocol compatible devices found in industrial applications. With the XNX, you are freed from the need to add extra controllers, junction boxes, relays, monitors and other equipment accessories. The integration of our EDDL software also enables the XNX to work with a number of third-party distributed control systems (DCS).
With 200+ unique configurations, XNX satisfies Class 1/Class 2 intrinsically safe, explosion-proof requirements in upstream/downstream oil, chemical, wastewater and other industries.
Material Housing: 5-coat marine finish painted aluminium alloy or 316 stainless steel
Weight (Approx.) Aluminium alloy: 2.8kg (6.2lbs). 316 stainless steel: 5kg (11lbs)
Mounting Surface mount via integral mounting lugs. Optional pipe mounting kit suitable for Ø100mm to 150mm (Ø4” to 6”) pipe. Optional ceiling mounting bracket
Entries 5 conduit/cable entries (2 right, 2 left, 1 bottom). Entry size M25 for ATEX/IECEx versions or ¾"NPT for UL/CSA certified versions
Dimensions 160mm x 197mm x 114mm (6.1" x 7.8" x 4.5")
IP Rating IP66 in accordance with EN60529:1992. NEMA 4X
Operating Temperature -40ºC to +65ºC (-40ºF to +149ºF)
Operating Humidity 0-99%RH (non condensing)
Operating Pressure 90-110kPa
Storage Conditions -40ºC to 75ºC (-40ºF to 167ºF), 0-99% non-condensing
